Packaging & Delivery
| Packaging Details: | servo motor encoder packing: Carton |
|---|---|
| Delivery Detail: | 5 working days after receipt of payment, quantity depends! |
18 MONTHS: Free Replacement of Defective Products within 18 Months
DVC48T 9mm taper shaft servo motor encoder UVW motor encoder 8 poles
Advantage of DVC48T 9mm taper shaft servo motor encoder UVW motor encoder 8 poles
1, Certification: CE & ISO9001 & SGS.
2, Feature: sturdy and durable, easy to install, optional various output mode, etc.
3, Application: Widely used in the field of automatic control AC servo unit, particularly suitable in servo motor supporting.
Technical Parameter of DVC48T 9mm taper shaft servo motor encoder UVW motor encoder 8 poles
|
MECHANICAL SPECIFICATIONS | |
|
External Diameter |
48mm |
|
Hole Diameter |
8(straight hole)/9mm(1:10taper hole) |
|
Slew Speed |
8000r/min |
|
Shaft Load |
≤10N |
|
Operating Temperature |
-20 °C(-40 °C)- +85°C |
|
Protection Class |
IP50 |
|
Termination |
G |
|
ELECTRICAL SPECIFICATIONS | |
|
Supply Voltage |
DC5V |
|
Output Model |
L |
|
Frequency Response |
0-200kHz,300kHz |
|
Current Requirement |
≤60mA |
|
Output Pulse No. |
2500 |
|
Index Length |
1T |
|
Output Phase |
A,-A,B,-B,Z,-Z,U,-U,V,-V,W,-W |
|
Motor Pole Number |
2P,3P,4P,5P |
|
TERMINATION | |||
|
G Side Entry Cable |
E Rear Entry Cable |
C Side Entry Plug |
R Rear Entry Plug |
|
OUTPUT MODEL | |||
|
E Voltage |
F Complementary |
C Open Collector |
L Line driver or according to user requirement |
| Model defined: | |||||||||
| DVC | 48 |
T |
8 |
G |
05 | L |
2500 |
B |
M |
|
E:Economical R:Universal D:Reinforced H:High Precision Reinforced RDD:Magnetoelectric |
Body Diameter Ø 37mm |
S:shaft H:End Hollow Shaft(Blind Hole) T:Through Hollow Shaft(ViaHole) |
Shaft Diameter 8/9mm |
G:Side Entry Cable E:Rear Entry Cable C:Side Entry Plug R:Rear Entry Plug (G) |
Supply Voltage (DC5V)
|
Output Model: E:Voltage F:Complementary C:Open Collector L:Line driver or according to user requirement |
Output Pulse No. |
Output Phase B=A,B signals |
M=Index Signal |
Product Image of DVC48T 9mm taper shaft servo motor encoder UVW motor encoder 8 poles speed sensor
Mechanical Drawing of DVC48T 9mm taper shaft servo motor encoder UVW motor encoder 8 poles
Pre-sales Service of DVC48T 9mm taper shaft servo motor encoder UVW motor encoder 8 poles
1.The servo motor encoder sensor can be customized to meet your need.
2.The questions about the encoder will be answered within 24 hours.
3.We have the best after-sale service.
 |
 |
 |
 |
 |
 |
 |
|
Our Services
FAQ
MOQ 1 Set
Term of Payment T/T Western Union PayPal
Supply Capability 5000 sets / Week
Packing Carton
Delivery Time 5-7 working days after payment reached
Q1:Can I have a sample for testing?
A: Actually we have a very good price principle, when you make the bulk order then cost of sample will be return to you. The price is the same for 1-30 sets including the sample
Q2:Can I add my logo on the encoder ?
A:Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q3:How can i get the after-service?
A:We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
For our range hood motors it is lifelong maintenance.
Q4 :Do you have inspection procedures for encoder ?
A:100% self-inspection before packing
Q5:Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.
Here is our factory address: No.816-2, Pudong Road, Changchun, China
We can pick you up in the airport.
Hotel booking service is available
